PSH Multilevel Puzzle Parking Auto Efficient Lift and Slide

https://youtu.be/-1eTGh27QTY

Technical Parameter

Car Type
Car Size	Max Length(mm)	5300
	Max Width(mm)	1950
	Height(mm)	1550/2050
	Weight(kg)	≤2800
Lifting Speed	4.0-5.0m/min
Sliding Speed	7.0-8.0m/min
Driving Way	Steel Rope or Chain&Motor
Operating Way	Button,IC card
Lifting Motor	2.2/3.7KW
Sliding Motor	0.2/0.4KW
Power	AC 50/60Hz 3-phase 380V/208V





























Space-Saving Smart Parking Solution for Urban Areas

In modern cities, limited land resources and increasing vehicle ownership make parking space a critical challenge. Our Lift and Slide Mechanical Parking System is specifically designed to maximize parking capacity within restricted spaces, offering a safe, reliable, and cost-effective solution for residential, commercial, and public parking projects.

By combining vertical lifting and horizontal sliding technologies, this system significantly increases the number of parking spaces while minimizing land occupation, making it an ideal choice for urban renewal projects, commercial complexes, office buildings, hospitals, and residential communities.

Key Advantages

1. Maximum Space Utilization

The lift-and-slide design enables multi-level parking within limited ground space, increasing parking capacity by 2 to 6 times compared with conventional parking methods. It efficiently solves parking shortages in high-density urban areas.

2. Stable & Reliable Operation

Adopting advanced transmission systems such as steel rope or chain & motor drive, the equipment operates smoothly with low noise and high stability. Precision manufacturing ensures long-term reliable performance with minimal maintenance requirements.

3. Flexible Layout & Custom Design

The system can be flexibly designed according to site conditions, land shape, building structure, and user requirements. It supports installation in basements, ground-level areas, and pit-type structures, making it suitable for a wide range of project scenarios.

4. High Safety Standards

Equipped with anti-fall devices, photoelectric sensors, emergency stop buttons, and intelligent interlock systems, the parking system provides comprehensive safety protection for both vehicles and operators, fully complying with international safety standards.

5. Intelligent Control & Easy Operation

The PLC control system supports button control, IC card operation, and LCD display interface, enabling simple, intuitive, and user-friendly operation. Drivers can park and retrieve vehicles conveniently with minimal training.

6. Durable Structure & Long Service Life

All steel structures undergo shot blasting and full zinc coating surface treatment, offering superior corrosion resistance. The system is designed for over 35 years of anti-corrosion performance, ensuring long-term durability even in harsh environments.

7. Cost-Effective Investment

With optimized structural design, standardized components, and efficient manufacturing, this system delivers excellent performance at a competitive price, helping investors achieve faster ROI and lower lifecycle costs.

Typical Applications

Residential communities & apartment complexes

Commercial buildings & shopping malls

Office buildings & business parks

Hospitals & public institutions

Hotels & mixed-use developments

Urban renewal and retrofit projects

Company Introduction

Jinguan has more than 200 employees, nearly 20000 square meters of workshops and large-scale series of machining equipment, with a modern development system and a complete set of testing instruments.With more than 15 years history, the projects of our company have been widely spread in 66 cities in China and more than 10 countries such as USA, Thailand, Japan, New Zealand, South Korea, Russia and India. We have delivered 3000 car parking spaces for car parking projects, our products have been well received by customers.

Certificate

Why Choose Our Lift and Slide Parking System?

With over 15 years of manufacturing experience, advanced CNC production equipment, and a professional engineering team, we provide customized solutions, strict quality control, and full lifecycle service support, including design, manufacturing, installation, commissioning, and after-sales service.



Our systems have been successfully delivered to 66 cities in China and more than 10 countries worldwide, earning high recognition from global customers.

Professional Service & Support

Site evaluation & customized layout design

Structural and electrical engineering support

Installation guidance & commissioning

Operator training

Long-term technical support & spare parts supply

FAQ

Q1: What types of projects is the lift and slide parking system suitable for?

This system is widely used in residential complexes, commercial buildings, office parks, hospitals, hotels, and urban renovation projects. Thanks to its flexible design, it can adapt to various site conditions, including limited land areas, irregular layouts, and underground spaces.

Q2: Can the system be customized according to our site dimensions?

Yes. We provide fully customized design solutions based on your site drawings, land size, building structure, column spacing, vehicle types, and traffic flow. Our engineering team will optimize the layout to ensure maximum space utilization and smooth vehicle access.

Q3: What is the typical installation time?

Installation time depends on project scale and configuration. Normally, standard projects can be completed within 15–30 days, including mechanical installation, electrical connection, testing, and commissioning.

Q4: Is the system safe for daily operation?

Absolutely. The system is equipped with multiple safety protection mechanisms, including anti-fall devices, vehicle detection sensors, emergency stop buttons, and intelligent interlocking systems. All units undergo strict factory testing before delivery to ensure long-term operational safety.

Q5: What kind of maintenance is required?

Routine maintenance is simple and cost-effective. We provide detailed operation and maintenance manuals, along with remote technical support. With proper routine checks, the system can operate stably for many years with minimal maintenance costs.

Q6: Can the system be integrated with existing parking facilities?

Yes. The lift and slide parking system can be integrated with existing garages, basements, and building structures, making it ideal for renovation and expansion projects without major civil construction.

Q7: How is after-sales service handled for overseas projects?

We offer global after-sales support, including remote technical guidance, online troubleshooting, installation supervision, and spare parts supply. For large-scale projects, on-site engineering support can also be arranged.

Q8: What information is needed to provide a quotation?

To prepare an accurate proposal, we recommend providing:

Site layout or architectural drawings

Available land dimensions

Required parking capacity

Vehicle size range

Installation location (above ground / underground / pit type)

Based on this information, our engineering team will prepare a customized layout design and detailed quotation tailored to your project requirements.

Interested in our Lift & Slide Parking System?

Feel free to contact our team for technical details and project consultation.
